10KV Insulated piercing connectors絕緣穿刺線夾

: ~~暂无价格~~

产品说明
English

品牌：法國�？罚⊿ICAME Group）,正宗法國進口。

● 連接器主體采用高強度，高度抗老化的絕緣材料制成。

● 安裝簡便，運行安全。

● 連接器主線與支線端同時穿刺。

● 螺栓經防腐熱鍍鋅處理，不與導體接觸。

● 密封防水支線端蓋，可防止水侵入支接導線，保證絕緣性能。端帽可自由移取，支線可選擇從左側或右側連接。

● 恒定力矩螺母控制穿刺力度，確保最佳電氣連接效果。

● 根據�？芳瘓F(tuán)技術標準：STS 00021。

●該系列穿刺線夾均產自法國，采用全球先進的制造設備、一流材質及生產技術和工藝。

● 產品符合以下國際、國外、國內標準：EN 50397-2 (03-2010)、IEC60998-2-3:2002、EN 50483-4、GB 13140.4-2008、DL/T758-2009、GB4208-2008、GB/T5169.10-2006、DL/T765.3-2004、GB/T2314-2008、GB/T9327-2008及DL/T1190-2012。

●本產品均按照以下標準在武漢高壓研究所電力工業電氣設備質量檢驗測試中心進行檢測，所有測試全部通過：GB/T 5169.10-2006及DL/T 765.3-2004。

Application for 35KV and below overhead covered conductor connection and branch.

Main /Tap : Cu,Alu or Alu-alloy cable.

● Watertight connector with an insulating body highly climatic andmechanically resistant.

● Easy to install and safe to use.

● Simultaneous insulation piercing on main and tap.

● Voltage free tightening with hot dip galvanized screws.

● Water penetration in the branch cable prevented by an insulating end cap equipped with a water seal . The branch can be on the leftside or on the rightside.

● Perfect design of shear-off head screw with the right torque guarantees the best electrical connection performance.

● In accordance with STS 00021 SICAME Technical specification.

●This series of insulated piercing connectors are produced in France with the world advanced manufacturing equipment, first-class materials and manufacturing technology and process.

● The products are manufactured in accordance with the following international and Chinese standards: EN 50397-2 (03-2010) ；IEC60998-2-3:2002；EN 50483-4；GB 13140.4-2008；DL/T758-2009；GB4208-2008；GB/T5169.10-2006；DL/T765.3-2004；GB/T2314-2008；GB/T9327-2008 and DL/T1190-2012.

●The products have passed the full range of tests in Wuhan Test Center for Electric Power Equipment in accordance with the following standards: GB/T5169.10-2006 and DL/T765.3-2004.
